Industrial computed tomography for non-destructive component testing, high-resolution 3D analyses, and reliable quality assurance.
We support companies from Aalen, Germany, and internationally with precise CT analyses for industry, aerospace, medical technology, research, and development.
State-of-the-art CT technology for results with the highest accuracy and level of detail.
Your components remain intact and safe during the analysis.
Short analysis times and digital results for quick and well-founded decisions.
Tailored analyses and consulting, aligned with your requirements.
With industrial computed tomography, we analyze components non-destructively and with the highest precision. From high-resolution 3D visualization and measurements to defect analysis, you receive reliable results for development, quality assurance, and production. Each analysis is individually tailored to your requirements and conducted with the latest CT technology.
Take a look behind the scenes of our company. From state-of-the-art CT technology to our work environment and our team, you get an authentic impression of our daily work and our high quality standards.
Our industrial computed tomography produces high-resolution three-dimensional models of your components and assemblies. This makes even complex internal structures visible without damaging the component. The obtained CT data enable detailed analysis, clear documentation, and well-founded technical decisions.
Whether in development, quality assurance, or damage analysis – 3D visualization creates transparency and provides valuable insights into the structure, geometry, and material behavior of your products.
Industrial computed tomography allows non-destructive detection of shrinkage cavities, porosities, cracks, inclusions, delaminations, and other material defects. Even defects inside complex components become visible without damaging the workpiece.
Our analyses support you in root cause investigation, optimization of manufacturing processes, and reliable quality assurance.
We inspect components for dimensional accuracy and compare geometries with the highest precision. Even the smallest deviations are reliably detected and documented.
CT-supported measurement is especially suitable for complex internal geometries that are difficult or impossible to access with conventional measurement methods.
By comparing CT data with your CAD models, geometric deviations become quickly and reliably visible. Color deviations immediately show where components are outside tolerances.
This provides a reliable basis for approvals, optimizations, and continuous improvement of your manufacturing processes.
Existing components are fully digitized and analyzed using computed tomography. The generated datasets form the basis for reconstructions, documentation, or further development of existing products.
Reverse engineering is particularly suitable when no or only incomplete design data are available.
We analyze porosities within your components regarding size, location, and distribution. Modern evaluation methods enable both automated analyses and manual assessments according to defined quality requirements.
The results provide a solid foundation for assessing component quality and optimizing manufacturing processes.
With wall thickness analysis, we check material distributions, wall thicknesses, and critical areas within complex components. The color-coded visualization immediately highlights differences and supports the optimization of designs and manufacturing processes.
This analysis provides valuable insights, especially for plastic parts and additively manufactured components.
We have powerful industrial CT systems available for different component sizes, materials, and inspection tasks. This allows us to analyze both small, detailed components and larger assemblies precisely, non-destructively, and reliably.
Technical Data
ZEISS METROTOM 1500
Waygate v|tome|x M
X-ray Tube
Microfocus 225 kV
Microfocus 240 kV
Detector
3000 × 3000 px
2000 × 2000 px
Minimum Voxel Size
7 µm
2 µm
Maximum Sample Size
Ø 770 mm, Height 1,500 mm
Ø 500 mm, Height 1,100 mm
Scan Area
Ø 615 mm, Height 800 mm
Ø 420 mm, Height 500 mm
Maximum Component Weight
50 kg
50 kg
Our industrial computed tomography is suitable for components made from a wide variety of materials. From metals and plastics to ceramics and fiber-reinforced composites, as well as electronics and complete assemblies, we analyze even complex structures precisely, non-destructively, and reliably.
Our industrial computed tomography is used across a wide range of industries.
With our experience, we support companies in the analysis, measurement, and quality assurance of complex components, from individual inspections to series production.
Inspection of components for drive, safety, and comfort.
Highest safety for critical components and structures.
Analysis of implants and medical devices for maximum safety.
Quality assurance and optimization of complex machine components.
Analysis of printed circuit boards, connectors, and electronic components.
Inspection of plastic components for quality and dimensional accuracy.
Support in material research and product development
Non-destructive analysis of valuable objects and finds.
Let’s discuss your project. We support you with top-class CT technology, experience, and personal consultation.
Our structured process ensures that you receive the insights you need for your decisions quickly, reliably, and with the highest quality.
We discuss your requirements and find the best solution for your component.
Your component is securely prepared and scanned with state-of-the-art CT technology.
A high-resolution 3D model of your component is created from the raw data.
We inspect, measure, and evaluate—precisely according to your specifications and standards.
You will receive clear results and a detailed inspection report.
Our processes are aligned with the highest quality standards and industry-specific requirements. With many years of experience and a consistent understanding of quality, we ensure precise, transparent, and reliable results.
Upon request, you will receive a digital twin of your component. This allows you to analyze geometries and internal structures as well as use the data for measurements, simulations, or documentation.
We provide the appropriate data formats and evaluations – tailored individually to your requirements.
